Ejector seat for light aircraft

[Bennyboy320]

It was a Mirage A3-29 pilot was FLTLT Garry Cooper of 75 Sqn May66.





[facthunter]

Thanks for the correction. I used to fly into that strip to pick up charters.. Had trees down both sides and not wide. . Another RAAF plane fell into shops at the Junction, near Bar Beach. Nev





[rgmwa]

Then again, he was married.

Yes, in my experience that usually transforms you into an accessory.

rgmwa





[facthunter]

A married partner cannot be required to give evidence against their spouse. A lot of them enjoy it. Nev





[Methusala]

I remember the MIG-15 crash. Some believe that he tried to avoid hitting an active, populated sports field and stalled/spun into a road embankment. Perhaps, had he and passenger banged out, the aircraft may have hit the oval with greatly increased loss of life. (This is merely conjecture based upon rumors) Don





[poteroo]

It was a Mirage A3-29 pilot was FLTLT Garry Cooper of 75 Sqn May66.

the Garry Cooper,DFC, who went on to become a Forward Air Controller flying Birddogs in Vietnam and became a 747 Captain with Ansett? His book, Sock it to 'em, baby, details his escapades in Vietnam. happy days,





[Garfly]

Maybe time to give this famous old photo a re-run.



Surprisingly not a fake ... by all accounts.





"George Aird, DeHavilland test pilot ejects from Lightning PB1 XG332 on 13th September1962." carrying out demonstration flight when there was a fire in the aircraft's reheat zone. This weakened the tailplane control system which failed with the aircraft at 100ft on final approach. Fortunately the nose pitched up, giving Aird time to eject. He came down through a greenhouse roof, breaking both legs and right thigh. He recovered to resume his flying career. I believe the photograph was for a farming magazine, with only the tractor planned to be in shot!



The above description quoted from here:



http://forum.keypublishing.com/showthread.php?97786-Lightning-XG332-Crash-escape-photo&s=f742e8345fa80f11c9bf3accb757e7b3





[pylon500]

Have seen the photo before, and while appears legit, one wonders how the pilot becomes to be lower than the plunging aircraft?



There are some wild gyrations possible to explain all relevant positions, so who knows.



Another example of seemingly unrelated angles would this Andover crash, which looks to be going straight in, but is actually stalling and cartwheeling down the runway, most of the crew got out!







[Zibi]

Since we're sharing old photos and stories, I wonder how long until we end up with a story like this from one of those planes with ejector seats:





http://www.vfp62.com/f14_rio.html



F-14 Passenger Ejects"I'VE LOST MY RIO"



by Lt. Geoff Vickers



My squadron and air wing were detached to NAS Fallon, Nevada, for strike training. Most of us attended lectures all day, but I was tasked with giving the battle-group-air-warfare commander an orientation flight in the F-14D. As skipper of the cruiser in charge of the battle group's air defenses, he had been spending time with the air wing to better understand how we conduct our missions. He had observed a number of the strike events through the tactical-air-combat-training system (TACTS) replays, and he had flown with the E-2C and EA-6B squadrons. He was proud that the Prowler guys hadn't been able to make him sick.



My job was to demonstrate the Tomcat's performance and tactical capabilities. Though this flight was my first without a qualified radar-intercept officer (RIO) in the back seat, I had flown with a number of aviators who had very little Tomcat experience.



The Captain arrived at the squadron a half-hour before the brief to receive his cockpit-orientation lecture and ejection-seat checkout. Once in the ready room, we briefed the flight with our wingman. I covered the administrative and tactical procedures in accordance with our squadron's standard-operating procedures (SOP).



I told the Captain that after the G-awareness maneuver, we would do a quick inverted check to verify cockpit security. Looking back, I should have recognized his anxiety when he mocked me and said, "Just a quick inverted check?" then laughed. I didn't realize hanging upside down with nothing but glass and 11,000 feet of air separating you from the desert floor might not be the most comfortable situation in the world for a surface-warfare officer.



I continued the brief and told the captain we would do a performance demo and a couple of intercepts, followed by tanking from an S-3. I told him if, at any point, he felt uncomfortable, we would stop whatever we were doing, roll wings level, and take it easy. I was determined to avoid the temptation to intentionally make him sick and uncomfortable.



The start, taxi, and takeoff were normal. We joined with our lead and did the standard clean-and-dry checks. We pressed into the working area and assumed a defensive combat-spread formation in preparation for the G-warm. I told him what was happening, and he seemed to remember the sequence of events from the brief. After we completed the checks, I asked him, "Are you ready for the inverted check? Do you have everything stowed?" All set" was the last thing I heard him say.



I checked the airspeed and confirmed it was above the 300 knots recommended to do the check, and I rolled the aircraft inverted. I decided not to really put on a lot of negative G and unloaded to about .3 to .5 negative G's-just enough to make anything float that wasn't stowed properly. If he was uncomfortable in such a benign maneuver, it would be better to find out then, rather than when we were racing toward the earth during a radar-missile defense.



As I started to push on the stick, I heard a loud pop, followed by a roar. The cockpit filled with smoke, and we suddenly lost cabin pressure. I first thought a catastrophic environmental-control system (ECS) had failed. I said to myself, "This is new. I've never even heard of something like this happening."



Time compression turned the next few seconds into an eternity. I knew the first thing I had to do was to roll the jet upright and assess the situation. About three seconds after the first indication of a problem, I had the jet upright and knew exactly what had happened. transmitted, "Lion 52. Emergency, my RIO just ejected."



I was yelling into the mic, thinking I would have to make all the calls in the blind. I never would have thought I easily could communicate with all the noise of flying at 320 knots without a canopy. As I turned the jet to try and get a visual of my wayward passenger, Desert Control asked,"Understand your wingman ejected?" "Negative, my RIO ejected. I'm still flying the plane." "OK. Understand your RIO ejected. You're flying the plane, and you're OK?"



I almost said I was far from OK, but I just told them I was all right, except I was flying a convertible. I was relieved to see a good parachute below me, and I passed this info to Desert Control. Very quickly after the emergency call, an FA-18 pilot from the Naval Strike and Air-Warfare Center, who also was in the area, announced he would take over as the on-scene commander of the search-and-rescue (SAR) effort.



I told my wingman to pass the location of the Captain because I could not change any of my displays. Once my wingman started to pass the location, I started dumping gas and put the needle on the nose back to NAS Fallon.



One of our air-wing SH-60s was in the area and responded, along with the station's UH-1N. The Captain was recovered almost immediately and transported to the local hospital for treatment and evaluation. The only F-14D boldface procedures for a canopy problem include placing the canopy handle in "boost close" position and then moving the command eject lever to "pilot." Obviously, the canopy already was gone, so that lever action didn't apply, and, if the command-eject lever wasn't already in "pilot," as briefed, I also would have been ejected.



I slowed the aircraft and lowered my seat because that's what I remembered from the rest of the steps in the checklist. However, after sitting at eye-level with my multi-function display for about 30 seconds, I thought it would be more prudent to see outside, so I raised my seat. Slowing the aircraft had little affect on the windblast, but, as long as I leaned forward, the wind hit only my shoulders. Because it was very cold at altitude, I decided to return quickly to base, but I needed to watch my airspeed since the ejection had occurred.



The PCL says to fly less than 200 knots and 15,000 feet and to complete a controllability check for the loss of the canopy, but I never pulled out my PCL to reference it. I figured with the way my day was going, I'd probably just drop my PCL down an intake and complicate my problems. In retrospect, I should have requested my wingman break out his checklist and talk me through the steps. Though this practice of having a wingman assist is common in single-seat communities, Tomcat crews tend to forget this coordination technique is a viable option.



I did consider the controllability check, and I directed my wingman to check for damage to the vertical stabilizers-she found none. The faster I got on deck, the faster I would get warm. I slowed to approach speed in 10-knot increments at about 3,000 feet AGL and had no problems handling the jet. As I approached the field, I was surprised at how quiet it got. The noise was only slightly louder than the normal ECS roar in the Tomcat. I'll admit I felt silly saying the landing checklist over the ICS when no one else was in the cockpit, but I didn't want to risk breaking my standard habit patterns.



The landing was uneventful, and, when I pulled back into the line, I was surprised to find how many people had come out to see the spectacle. The magnitude of the situation finally set in when my skipper gave me a hug after I got out of the jet.



The Captain and I were very fortunate: All of the ejection and aviation-life-support-systems (ALSS) equipment functioned as expected. Our PR1 had taken the time to properly fit the captain, using components from three different sets of flight gear. This action caused a problem after the mishap-getting everyone's gear replaced-but it renewed my faith in our escape systems. A 48-year-old man ejected from the jet when it was inverted, at negative .5 G's, at 320 knots, and the only injuries he had were two minor cuts to his face.



After talking to the Captain at the O'Club later that night, I realized I better could have briefed elements of the flight. Though I covered all of the details, I didn't fully consider his perspective. He said he didn't know where to put his hands. Consequently, he just left them in loosely clenched fists on his lap, about two inches away from the ejection handle. It never occurred to me that someone would not know what to do with his hands. Obviously, I fly with the stick and throttle in my hands 95 percent of the flight, but I failed to consider his situation.



The mishap board surmised that, during the inverted maneuver, he must have flinched when he slightly rose out of the seat and pulled the ejection handle. Now, before any brief, I try to place myself in the other person's shoes (even if they are black shoes) and imagine what the flight will be like for him. Whether it is the person who never has flown a tactical aircraft before or just the nugget pilot who never has flown with NVGs, remembering what it was like when I was unfamiliar with the environment will prevent this type of mishap from recurring.



Contributed by Scott Ruby & Jim "Mugs" Morgan VFP-63

[Garfly]



Our modern GA equivalent of Pylon's Andover.



Looks worse than it was. A nose-wheel collapse on landing, neither seriously hurt - as I remember.





[Yenn]

Interesting story by Geoff Vickers.



The tractor photo looks odd to me. How would the tractor driver have known to look at the plane. I know from experience that the tractor noise would have masked the plane, also it looks as if the tractor was pulling a mower and the photographer was in danger of getting his feet cut off.





[Garfly]

Yes, I know, Yenn, the 'tractor nearly hit by lightning' pic looks so suss in so many ways. It's the perfect composition that worries me most. But, it seems to be so well known and accepted as legit that I'm putting it in the 'truth is stranger than friction' basket.



;-)





[Old Koreelah]

...How would the tractor driver have known to look at the plane. I know from experience that the tractor noise would have masked the plane...

I'd have thought that as well Yenn, but experience says otherwise. While operating a Michigan loader near Bankstown in 1971 I heard a noise and looked up to see a P-51 flying over at 1000 feet or more. I heard the Merlin over the scream of the unmuffled exhaust a couple of metres behind me.

No wonder I'm deaf.





[facthunter]

That looks like a fairly good order Fordson Major with normal muffler. I can usually hear an aircraft long before I see it. The ejector seat cartridge is probably loud enough. Nev





[Guest ozzie]

I had a aviation book with that photo in it when i was a kid. I think it also features in the book 'Into the Silk' about the Caterpillar Club.





[Phil Perry]

It's a bit of a shame really that photographs such as that create almost immediate suspicion of a "PHOTOSHOP" Job,. . . . . I also saw that photo when I was an air cadet in 1964, with hindsight, it is surprising that the M.O.D. Didn't classify it ( ! ) when it was relatively recent, and no one seemed to question it's validity then. . . . .



Reading the text from the link, It states that "fortunately, the nose pitched up, . . . which at around 200 MPH, would certainly have at least momentarily arrested the descent, and quite possibly have resulted in a brief increase in height agl,. . . allowing ( Evidently ) sufficient time for the pilot to operate an auto vacate handle, before the thing stalled and fell out of the sky.



On the particular type of ejection seat unit fitted to Early Lightnings, one above your head, pulling a face protector down with it, and one smaller one between your legs, which only has to be displaced upward by around a quarter of an inch, (or five and a bit mil ) to allow fast operation in case of high positive G forces in the event of a serious loss of control. ( Most seats have the same system in later aircraft, albeit some being perhaps "Eject by wire" in severe circumstances. . . . )



Anyway,. . . . good thread,. . . . though I still think I'd prefer a leisurely ride to the ground on the end of a BRS in my LSA, . . . . rather than sitting on a firework, and having to employ an armourer on the ground to activate / deactivate the system every flight ( ! )



Phil





[Marty_d]

It's a bit of a shame really that photographs such as that create almost immediate suspicion of a "PHOTOSHOP" Job,. . . . . I also saw that photo when I was an air cadet in 1964, with hindsight, it is surprising that the M.O.D. Didn't classify it ( ! ) when it was relatively recent, and no one seemed to question it's validity then. . . . .Reading the text from the link, It states that "fortunately, the nose pitched up, . . . which at around 200 MPH, would certainly have at least momentarily arrested the descent, and quite possibly have resulted in a brief increase in height agl,. . . allowing ( Evidently ) sufficient time for the pilot to operate an auto vacate handle, before the thing stalled and fell out of the sky.



On the particular type of ejection seat unit fitted to Early Lightnings, one above your head, pulling a face protector down with it, and one smaller one between your legs, which only has to be displaced upward by around a quarter of an inch, (or five and a bit mil ) to allow fast operation in case of high positive G forces in the event of a serious loss of control. ( Most seats have the same system in later aircraft, albeit some being perhaps "Eject by wire" in severe circumstances. . . . )



Anyway,. . . . good thread,. . . . though I still think I'd prefer a leisurely ride to the ground on the end of a BRS in my LSA, . . . . rather than sitting on a firework, and having to employ an armourer on the ground to activate / deactivate the system every flight ( ! )



Phil

If you saw it in 1964 I think we can say with some certainty that it wasn't photoshopped!





[Zibi]

If you saw it in 1964 I think we can say with some certainty that it wasn't photoshopped!





[Phil Perry]

QUOTE="Zibi, post: 475350, member: 6918"]



Get orf the Grarse Zibi. . . . .Anyone can see that's not Adolf Schickelgruber in that photo, . . and anyway his hair is combed the wrong way!





[Phil Perry]

More on the George Aird Lightning ejection incident.



I found this quite interesting so did a quick bit of research in the wee small hours of Sunday Morning. . . . . apaologies for timewasting if you have already seen this stuff.



Photos of the site with some detail



http://www.rafjever.org/118sqnper002.htm



Here’s an email from Mick Sutterby the tractor driver in the original photograph ( Scroll down the page a little )



http://www.rafjever.org/118sqnper002.htmhttp://fearoflanding.com/photography/the-story-behind-an-unbelievable-photograph/



It is interesting to note that following the RAF lifting the three month restriction of the “Secret” aircraft photo. . ., the Daily Mail refused to accept the photograph, labelling it a fake ! ! ! so the Daily Mirror got the kudos ! Some things never change.



Phil.





[Bruce Tuncks]

I'm not getting an ejection seat for my SK jabiru. There was an English Electric Lightning which killed the pilot when he activated the ejection seat on the ground after doing a dead-engine landing. AND the Jab being high wing would interfere with the ejection. I would hit the roof.





[Oscar]

I'm not getting an ejection seat for my SK jabiru. There was an English Electric Lightning which killed the pilot when he activated the ejection seat on the ground after doing a dead-engine landing. AND the Jab being high wing would interfere with the ejection. I would hit the roof.

And your legs would be broken by the front wing carry-through member even if they took the panel out ok..





[Old Koreelah]

And your legs would be broken by the front wing carry-through member even if they took the panel out ok..

The F/A-18 pilot's lower legs are attached to a harness which pulls them in to clear the panel before ejecting.





[Oscar]

The F/A-18 pilot's lower legs are attached to a harness which pulls them in to clear the panel before ejecting.

I suspect that in a F/A-18, there is a wee bit more forward space for the pilot's legs than in a Jab.! Also, in the Jab. the roof above your head is structural, therefore you can't just cut out a blow-off panel and not compromise the structure...



2 x 36(?) kgs seats, add chutes per occupant... actually, this is a BRILLIANT safety improvement!. Since you couldn't legally take off with two passengers, there's a potential halving of fatalities right there!



Talk about a solution to a problem that doesn't exist.....





[Phil Perry]

I'm not getting an ejection seat for my SK jabiru. There was an English Electric Lightning which killed the pilot when he activated the ejection seat on the ground after doing a dead-engine landing. AND the Jab being high wing would interfere with the ejection. I would hit the roof.

Geez Bruce, . . . . . some folks have NO sense of humour do they ? ? ? ? . . .oh, and the elderly Jet Provost ( along with quite a few other military aircraft over the years also had leg straps to prevent kneecap truncation during rapid vertical exit. . . .
