Bit by bit I've been ordering bits from evilbay and putting together the fuel system.
Manifold has the limiters tapped and loctited in the rear two outlets, starboard is return line to wing tank, 1/4 ally line going thru gland in the firewall, thru corner of dash, up beside the cabin tube and into the sill above the door and thence out to a quick release to the wing tank.
Port tune snakes around and thru the firewall above the passenger throttle rod, I have a barb fitted to the gauge so short rubber connection there too.
1/4 rubber lines are sheathed in fireproof cover, I have a bit left over so will cover as much as I can of the return / pressure gauge lines too when the next shipment of hose clamps arrives.
